SHAFT SERIES |
A |
B |
OUTER TUBE |
OUTER TUBE YOKE |
OUTER JOINT |
|
 |
30mm
1 3/16"
|
3mm
1/8"
|
|
Part No.
A10230
|
Part No.
A10002
|
|
|
41.3mm
1 5/8"
|
3mm
1/8"
|
|
Part No.
A20241
|
Part No.
A20002
|
|
|
Part No.
A11241
|
Order
parts
|
|
|
|
BOTH TYPES
USED
CHECK SIZE |
|
|
Standard for W210-W2300
Part No. A21241
|
Part No.
A21002
|
48mm
1 7/8"
|
4mm
5/32"
|
Spec. for 48mm tube
Part No. A21248
|
order parts
|
|
|
LEMON PROFILE TUBE
|
Part No.
A22248
|
Order
parts
|
|
|
48mm
1 7/8" |
4mm
5/32" |
For Lemon Profile Tube
Part No.
A35248
P400 Series - Use Bareco Guard |
|
Quick Release Type
A35005
1 3/8" x 6 Splines
for Lemon ProfileTube
P400 Series - Use Bareco Guard |
|
61mm
2 7/16"
|
4mm
5/32"
|
OPTIONAL
for W2400 Series.
Star Profile Tube as below |
For Star Profile Tube
Part No.
A35261
P400 Series - Use Bareco Guard |
|
Quick Release Type
A35002
1 3/8" x 6 Splines
for Star Profile Tube
P400 Series - Use Bareco Guard |
|
|
|
STAR PROFILE
|
Part No.
A23261
|
For Star Profile
Tube - Order
Component
Parts |
|
|
Part No.
A24261
|
|
|
Part No.
A36261
P500 Series - Use Bareco Guard |
|
|
|
|
71mm
2 13/16"
|
5mm
3/16"
|
|
Part No.
A026271
P600 Series - Use Bareco Guard |
|
|
|
71mm
2 13/16"
|
5mm
3/16"
|
|
Part No.
A027271
|
|
